RO (Reverse Osmosis) Water System

Category:

Commercial Brackish Water Reverse Osmosis System
AAMTAC supplies a full line of standard and fully customizable brackish reverse osmosis systems, all of which are engineered using advanced 3D computer modelling and process design software for accurate and customized solutions.

A significant aspect for the effective running of a brackish reverse osmosis system is the RO feedwater quality, which becomes resolved by the consistency of the water body and the success of the pre- treatment process.

Brackish RO systems require pre-treatment of which is always included in the sale unless the water is already being treated. Pre-treatment systems depend on the quality of water that is treated along with the application. Taking those two into account is how our engineers recommend the most appropriate pre/post treatment for the system. Components of pre/post treatment include multimedia and activated carbon filters along with water softeners and UV sterilizers. A chemical dosing system and/or a cleaning skid are also incorporated into the system.

Operation Specifications
  • Max. feed water temperature: 42°C
  • Equipment upgrade for TDS over 5,000 ppm
  • Hydrogen Sulfide must be removed
  • Max. Silica Tolerance: 60 ppm @ 60% recovery
  • Feed water TDS: 0-1,000 ppm
  • Operating pressure: 150 to 250 psi
  • pH tolerance range: 3-11
  • Max. Iron content: 0.05 ppm
  • Feed water pressure: 20 to 80 psi
  • Hardness over 1 GPG requires antiscalant dosing
  • Turbidity should be removed
  • Operate at higher TDS by lowering recovery
Standard Features: Available Options:
  • NEMA 12 enclosure
  • Low pressure switch
  • High pressure switch
  • Liquid filled pressure gauges
  • Permeate conductivity monitor
  • Permeate & concentrate flow meters
  • Powder coated carbon steel frame
  • 4” TFC spiral wound membranes
  • Stainless steel multi-stage pump with TEFC motor
  • FRP membrane housing
  • 5 micron cartridge prefilter
  • 460V/3Ph/60Hz power supply
  • Microprocessor based control panel
  • Programmable time delay and set points
  • Status indicators
  • Motor starter
  • Feed / Permeate blending
  • Export crating
  • 380-415V/3Ph/50Hz power supply
  • 220V/3Ph/60Hz power supply
  • Media and Iron prefiltration systems
  • Ozonation and UV sterilization systems
  • Water softeners
  • Post deionization polishers
  • Pre piped skid system
  • Product tank level controller switch
  • Feed pH monitor with sensor
  • Feed water conductivity monitor
  • Membrane cleaning skid
  • Automatic hourly flush
  • Feed ORP monitor with sensor
  • Water and hour meters
  • Chemical dosing systems
The ideal applications for brackish reverse osmosis systems include:
  • Rinse Water

  • Mining Industry

  • Chemical Blending

  • Laboratory

  • Beverage Production and Bottled Water

  • Spotless Car Wash System

  • Ion Exchange Pre-treatment

  • Boiler Feed Water

  • Food and Beverage

  • Safe Drinking Water

  • Electronics

  • Plating Operations

  • Ice Manufacturing

  • Power Plants

  • Metal Finishing

  • EDI Pre-treatment

  • Cooling Towers

  • Pharmaceutica
